High Speed Car Wash Machine
HZ-H9B(360) mini automatic car wash machine provide lower investment for car wash owners in order to deliver a better return on investment, specially designed for the car wash bays with limited sizes, suitable for car service station, petrol station, Auto dealers, 4S shop etc.
Description
Introducing the High-Speed Car Wash Machine
As a manufacturer located in China, we take great pride in presenting our latest innovation – the High-Speed Car Wash Machine. Designed to uproot the traditional methods of car wash, our machine is created to provide a hassle-free, efficient, and environmentally friendly solution to car owners and car wash business owners alike.
Our High-Speed Car Wash Machine comes with a range of features that make it distinctively superior to the conventional car wash methods. The machine is equipped with advanced technology that provides a fast wash and a thorough cleaning job with high efficiency. In approximately 3 minutes, our High-Speed Car Wash Machine can provide a comprehensive cleaning job that would take more time to complete with conventional methods.
The car wash machine features an efficient system that recycles and filters the water used during the washing process, minimizing water usage and keeping the environment clean. The reduced water usage also translates to a cost-effective solution as the owners can save money on water bills.
The High-Speed Car Wash Machine is designed for commercial use and can be used in various locations, including gas stations, car dealerships, parking lots, and other public areas. The machine is built with durability in mind, meaning it can handle high traffic environments without malfunctioning or experiencing downtime.
In terms of the car wash results, our High-Speed Car Wash Machine delivers outstanding cleaning, reaching areas that would be hard to reach with conventional methods. It can handle all types of vehicles, including sedans, trucks, and SUVs. It’s also suitable for cleaning other types of automobiles, including motorcycles, snowmobiles, and boats.
We understand that a car wash requires equipment that is user-friendly, and that’s why our High-Speed Car Wash Machine is designed with an intuitive interface that allows operators to manage the car washing process easily. Our machine’s touchscreen is user-friendly and can be customized for individual business owners' branding or languages to cater to the local customers.
Our High-Speed Car Wash Machine is a cost-effective solution because it operates with minimal staffing. With fewer staff needed for the washing process, business owners can save on labor costs while still offering a quality service. The machine is also designed with safety features in mind, keeping both the car owners and operators safe.
We take pride in our product, and we are confident that our High-Speed Car Wash Machine is a reliable solution that could benefit car owners and business owners alike. The machine’s design is environmentally friendly, cost-effective, and efficient, and it’s built with durability in mind, which makes it an excellent investment for commercial applications.
If you are looking for a reliable, efficient, cost-effective, and environmentally friendly car washing solution, our High-Speed Car Wash Machine is the best option. Please contact us today to schedule a demo to see how our car wash machine can transform your business operations.
high speed car wash machine



HZ-H9B(360) mini automatic car wash machine provide lower investment for car wash owners in order to deliver a better return on investment, specially designed for the car wash bays with limited sizes, suitable for car service station, petrol station, Auto dealers, 4S shop etc. Completely system include under chassis wash system, pre-soak application system, high pressure wash system, overglow Hi-gloss system, wax application system, chemical mixing system, intergrated air drying system, mounting frames. Minimum installation sizes: 7000mm*3300*3100mm ( L* W* H )
Functions:
1. High pressure pre-wash for under chassis and wheels.

2. Smart 360 rotate arm, spray various washing chemicals with high-precision proportioning technology.

3. Smart 360 rotate arm, Flush car body 360° with high pressure water.

4. HZ-H9B(360) mini Over-glow Hi-Gloss lava foam

5. Soft water with crystal wax coat

6. Integrated air drying system.
HZ-H9B(360) mini technical parameters
Item | Parameters/Process/Brand/Energy Consumption | Item | Parameters/Process/Brand/Energy Consumption |
Installation sizes | 7000mm*3300-3700*3100 | Towline cable | Germany IGUS (original import) |
Rail length | 7000mm | Longitudinal/transverse timing belt | Italy MEGADYNE |
Total power | 26kw | Reducer | Italy SITI |
Shipping weight | 2300kg | Wind drum/impeller | 304 stainless steel drum*galvanized plate impeller |
Shipping volume | 10CBM | Rotating arm | 304 stainless steel |
Power requirement | 16kw | Mainframe rack | Hot-dip galvanizing*outdoor plastic powder |
Control system PLC | Tainwan Delta Industrial PLC | Mounting frames | Hot-dip galvanizing, welding unnecessary |
Electrical components | French Schneider | HMI | 7 inch Delta colorful touch screen |
Ultrasonic sensor | German B+F (original import) | Drive system | French Schneider frequency conversion drive |
Water pump | Pinfl or Wuli high pressure pump | Pneumatic components | Taiwan airTAC |
Pump motor | Shanghai Lichao11kw/15kw/18kw | Nozzles | 304L stainless steel |
Air dryer motor | Germany Siemens aluminum motor | Rotary joint | American (original import) 304 stainless steel |
High pressure hose | American Packer | ||
Engineering towline | Germany IGUS (original import) |
HZ-H9B(360) mini installation and shipping dimensions
Item | Measurement | Specification | Volume |
A Max car wash height | 2000mm | Main machine polywood case | 3170*1260*1400=5.6CBM |
B Mainframe width | 3000mm | Water pump system polywood case | 1340*900*600=0.73CBM |
C Mounting width | 3300mm/3700mm | Mixing system polywood case | 900*550*1600=0.8CBM |
D Max car wash width | 2600mm | Frames | 17pcs=450kg |
E Machine height | 3050mm | Rails | 2pcs(7000*100*100mm)=205kg |
F Minimum installation height | 3100mm | Accessory | Pipes and other accessories |
H Frame mounting length (standard) | 7080mm | Total weight/Total volume | 10CBM/2300kg |
HZ-H9B(360) mini configuration
Item | Item | ||
24 hours self-service online paying | [√] | Remote control operation | [√] |
360 degree rotary high pressure flush | [√] | Alipay/Wechat payment system | [√] |
Intelligent chemical mixing system | [√] | LED arrow text remind system | [√] |
Soft water with crystal wax coat | [√] | Real voice guidance system | [√] |
Integrated air drying system | [√] | Operation authority setting | [√] |
Over-glow hi-gloss application system | [√] | Auto standby function | [√] |
Under chassis wash function | [√] | One button start/stop | [√] |
Multi liquid multiplexing function | [√] | System free upgrade service | [√] |
Indoor and outdoor mounting frames | [√] | 304 stainless steel automatic door | [ ] |
Digital safety collision avoidance system | [√] | Water recycling system | [ ] |
Car wash quantity summary | [√] | ||
Car wash mode selection | [√] | ||
Faulty self checking function | [√] | ||
Touch screen operation | [√] | ||
Description: [√] standard [ ] optional | |||
